DXF Files for CNC Cutting | MIlwaukee Packout Single + Quad Mount

Milwaukee Packout Single + Quad Mounting Plate DXF – Reversible, Logo Space, Bend Table Included

Grab this precision DXF file for your Milwaukee Packout Single + Quad mounting plate. Designed and verified in Southern California, USA by BOCO Custom—clean cuts, no guesswork.

Cut, bend per included table, and wall mount for a reversible plate that holds one single/half-width box + four accessory boxes. Room to add your own logo or graphic before cutting.

Why you'll love this DXF

• Plasma, Laser & Waterjet Ready — compatible with Aspire, Fusion 360, LightBurn, EnRoute, SheetCAM, most CNC software
• Precision-Cut & Verified — tested on ShopSabre Plasma Table and Xtool P2 Laser for smooth edges and reliable fits
• Bend Table Included — full drawings with bend lines and angles provided
• Instant Download — files delivered immediately, start fabricating today

Features & specifications

• File Format: High-quality DXF (clean vectors)
• Compatibility: Plasma, Laser, Waterjet CNC machines
• Software Tested: Aspire, Fusion 360, LightBurn, EnRoute, SheetCAM
• Process: Cut, bend, wall mount
• Extras: Bend table with drawings included
• Made: USA — BOCO Custom (Southern California)
• License: Create/sell physical products; no resale/sharing of files

Usage notes

1. Download ZIP instantly after purchase.
2. Import DXF into your CNC software.
3. Cut material of choice.
4. Bend per included bend table.
5. Mount to wall.
6. For issues, message us—we help you succeed.

Perfect for

Mechanics, fabricators, contractors, garages, workshops, vans, and anyone needing organized Packout accessory storage.

Important info

Digital download only—no physical item shipped. All sales final/non-refundable.

Download now and build pro-level Packout mounts. Thanks for supporting a small USA maker!

Raw Steel: Ships as bare metal—affordable, no added finish cost, and quickest to produce/ship. Ideal if you plan to paint it yourself, weld it further, or want a custom look (e.g., intentional patina or rattle-can paint). Note: Mild steel rusts quickly when exposed to moisture/humidity—store indoors and apply protection soon if used outdoors or in damp garages. Great for budget builds or immediate DIY finishing.

Powder Coat: A baked-on, professional-grade finish (textured black standard). Much tougher than regular paint—resists chips, scratches, fading, and rust far better. Provides excellent protection for job-site, vehicle, or outdoor use (like tool mounts in vans or garages). Adds a small upcharge but delivers a premium, long-lasting look with minimal maintenance. Powder coat also helps hardware stay functional longer by reducing wear.

How do I choose the right gauge for my project?

• Choose thicker gauges (10 or 11) for heavy-duty strength, structural parts, or high-load applications. Example: Using the plate on a horizontal application such floor or dolly.
• Choose thinner gauges (14) for lighter-weight parts, panels, or where cost matters more. Ideal for vertical applications suck as wall or bedside mount.

Why does gauge go backward (lower number = thicker)?
The gauge system originated from the number of draws needed to produce wire/sheet of that thickness. Fewer draws = thicker material = lower gauge number.
