DXF Files for CNC Cutting Bundle | Mounting Plates for Packout, Modbox & Buildout Digital Download

DXF Files for CNC Cutting Bundle for Storage System Mounting Plates

Grab this 5-file DXF bundle and start cutting custom mounting plates for your modular storage systems right away on your Plasma, Laser, or Waterjet CNC machine.

Designed and carefully verified right here in California, USA 🇺🇸 by BOCO Custom — exact fits, clean cuts, no wasted material, no alignment issues.

Includes ready-to-cut files for the most popular systems:
✅ Milwaukee Packout (dual full-width & single half-width sizes) (use 14 or 10 ga steel)
✅ Klein Tools MODbox (full-width & half-width sizes) (use 10 ga steel)
✅ Husky BuildOut (slim/low-profile design) (use 14 ga steel)

Perfect for fabricators, shops, garages, work vans, trailers, or job sites — create stronger steel versions tailored to your setup, avoiding high prices and long shipping waits on factory plates.

Why you'll love this DXF bundle
✅ Five Complete Files — Covers dual/single Packout, full/half MODbox, and Husky BuildOut — one bundle for multiple systems
✅ Inches AND Metric Provided — Every file in both imperial and metric units — universal compatibility, no conversion needed
✅ Ready-to-Cut Design — Pre-formatted, tested layouts — import and cut immediately, no cleanup or adjustments required
✅ Recommended Gauge — Designed & proven on 10, 12 & 14 gauge steel — durable, low-profile builds with reliable strength
✅ Software Compatibility — Optimized for Vectric Aspire, Autodesk Fusion 360, EnRoute, SheetCAM, LightBurn, and most other CNC/plasma/laser programs
✅ Instant Digital Download — Access all files immediately after purchase — start fabricating the same day

Usage & License
✅ You're welcome to use these files to create and sell your own finished physical products (mounting plates, custom storage solutions, etc.)
✅ Please do not resell, share, distribute, or modify and redistribute the DXF files themselves in any way — this protects the original design

Important Digital Product Info
➤ This is a digital download only – no physical item will be shipped
➤ Files delivered via Etsy instant download link (ZIP containing all 5 files in inches & metric)
➤ As a digital product, all sales are final and non-refundable
➤ If you run into any issues (file compatibility, download problems, etc.), message us right away — we're fabricators too and will help you get cutting
What's Included
➤ 5 high-quality DXF files (one for each system/size variation, inches primary + metric layers)

Download now and build custom, heavy-duty modular storage mounts with pro-level precision. 🛠️

Thanks for supporting a small USA maker!

Precision DXF Files for Fast CNC Production

These DXF Files for CNC are designed for makers, shops, and fabricators who need accurate cutting files for mounting plate projects. The bundle includes digital download files created for CNC cutting, helping you produce clean, repeatable parts with less setup time. Whether you are building custom storage upgrades or making shop-ready components, these files are made to support smooth workflow and reliable results. The designs are organized for practical use, so you can move from file to machine faster and with more confidence. This is a strong choice for anyone looking for dependable digital fabrication assets.

Compatible Mounting Plates for Packout, Modbox, and Buildout

This bundle includes mounting plate designs made for Packout, Modbox, and Buildout systems, giving you flexible options for different storage and organization setups. Each file is prepared with the goal of making CNC cutting simple and efficient while keeping the final fit functional and professional. These mounting plates are ideal for workshop storage, tool organization, and custom installation projects. By using ready-to-cut DXF formats, you can save time on drafting and focus more on production. The result is a practical digital file set that supports both small-scale projects and repeated shop use with consistent quality.

Instant Digital Download for Makers and Fabricators

As a digital download, this product gives you immediate access after purchase, making it a convenient solution for urgent jobs and planned builds alike. There is no waiting for shipping, so you can start preparing your CNC cutting project right away. The files are suitable for a range of users, from hobby makers to professional fabricators who need accurate output and efficient file preparation. With this bundle, you get a streamlined way to create mounting plates for popular storage systems without starting from scratch. It is a useful digital asset for anyone who values speed, precision, and easy access to production-ready design files.

Built for Clean Cuts, Reliable Use, and Easy Workflow

These DXF files are made to support clean cuts and dependable fabrication results across CNC workflows. The layouts are intended to help reduce waste, improve cutting accuracy, and keep your production process organized. Because the files are digital, they can be used again and again for projects that require consistency and repeatable results. This makes the bundle especially valuable for shops that produce mounting hardware or custom organizer parts on a regular basis. If you need a practical file set that combines usability, precision, and convenience, this product delivers a solid foundation for efficient CNC cutting work.

10-Gauge Steel (0.1345" | Thickness of Two Stacked Dimes)

• Best For: Heavy-duty commercial wall mounts, shop workbenches, and massive modular tool stacks.
• The Advantage: Extreme structural stiffness. This ultra-thick steel completely eliminates flexing, twisting, and tool rattling, making it the definitive choice for demanding daily job-site use.

12-Gauge Steel (0.1046" | Thickness of a Standard House Key)

• Best For: Mobile service vans, enclosed trailers, and standard shop organization layouts.
• The Advantage: The ultimate sweet spot between bulletproof strength and smart weight distribution. It handles constant over-the-road vibrations flawlessly without adding unnecessary bulk to your mobile rig.

14-Gauge Steel (0.0747" | Thickness of a Nickel)

• Best For: Handheld battery organizers, small tool holsters, and lightweight shelf accessories.
• The Advantage: High-tensile rigidity in a streamlined profile. It provides a rock-solid, permanent mount for smaller gear while keeping your workspace layout clean and low-profile.

8-Gauge Aluminum (0.1285" | Heavy-Duty Marine Grade)

• Best For: Open truck beds, roof racks, exterior trailer sides, and high-moisture environments.
• The Advantage: Maximum corrosion resistance with severe weight savings. Shaved pounds keep your mobile fuel efficiency optimized while remaining completely immune to rain, snow, and road salt oxidation.

10-Gauge Stainless Steel (0.1345" | Thickness of Two Stacked Dimes)

• Best For: Premium exposed truck bed brackets, marine applications, high-end shop builds, and ultimate weather protection.
• The Advantage: Combines the absolute, unyielding structural rigidity of our thickest 10-gauge plate with total lifetime corrosion resistance. It requires no paint or powder coat to stay 100% immune to rust, road salt, and harsh outdoor elements.

Note: Sheet metal gauge numbers run inversely—the lower the gauge number, the thicker and more rigid the actual metal substrate is.

We fabricate our mounting solutions and accessories using commercial-grade materials built for harsh environments. Choose the right finish for your build and review our care recommendations below:

Powder Coat Finish

• What it is: An industrial-grade, chip-resistant finish applied over media-blasted metal. Ready to install out of the box and engineered to survive heavy daily tool friction.
• Care: Low maintenance. Wipe down occasionally with a damp microfiber cloth to remove dust or workspace grime. Avoid using harsh chemical solvents or abrasive pads that could scratch the protective coating.

Raw Steel (Uncoated)

• What it is: Shipped as premium raw American steel that has been completely precision laser-cut, sanded, and deburred. Perfect for fabrication shops or DIYers who want to weld the brackets directly to a rig or custom paint them.
• Care: Requires immediate protection. Apply a clear coat or paint immediately after receiving to prevent surface oxidation (rust). Once coated, maintain with occasional wipe-downs using a dry cloth.

Painted Finish

• What it is: A clean, cost-effective protective coating applied in-house. Perfect for everyday indoor workspace use or setups that won't see extreme, heavy-duty metal-on-metal abrasion.
• Care: Moderate maintenance. Clean with a soft, damp cloth. Avoid harsh chemical solvents, degreasers, or abrasive scrubbing pads, as these can wear down or dull the paint over time. Minor touch-ups can easily be done with standard matching automotive or metal spray paint if scratched.

Aluminum (Uncoated)

• What it is: Premium, lightweight raw American aluminum that has been precision laser-cut and deburred. It offers excellent natural corrosion resistance without adding unnecessary weight to your mobile rig or vehicle setup.
• Care: Low maintenance. While it won't rust like raw steel, uncoated aluminum will naturally develop a dull patina over time when exposed to the elements. To maintain its bright, metallic shine, occasionally clean it with a dedicated aluminum cleaner or a light scotch-brite pad.

304 Stainless Steel

• What it is: Premium marine-grade stainless steel that is 100% rust-proof for life. Perfect for extreme outdoor environments, saltwater exposure, or applications where zero maintenance is required.
• Care: Virtually maintenance-free. Occasional rinses with fresh water in saltwater environments help maintain the pristine finish. No coating or paint needed—ever.
