DXF Files for CNC Cutting Bundle | Mounting Plates for Packout, Modbox & Buildout Digital Download

Grab this 5-file DXF bundle and start cutting custom mounting plates for your modular storage systems right away on your Plasma, Laser, or Waterjet CNC machine.

Designed and carefully verified right here in Southern California 🇺🇸 by BOCO Custom — exact fits, clean cuts, no wasted material, no alignment issues.

Includes ready-to-cut files for the most popular systems:
✅ Milwaukee Packout (dual full-width & single half-width sizes) (use 14 or 10 ga steel)
✅ Klein Tools MODbox (full-width & half-width sizes) (use 10 ga steel)
✅ Husky BuildOut (slim/low-profile design) (use 14 ga steel)

Perfect for fabricators, shops, garages, work vans, trailers, or job sites — create stronger steel versions tailored to your setup, avoiding high prices and long shipping waits on factory plates.

Why you'll love this DXF bundle
✅ Five Complete Files — Covers dual/single Packout, full/half MODbox, and Husky BuildOut — one bundle for multiple systems
✅ Inches AND Metric Provided — Every file in both imperial and metric units — universal compatibility, no conversion needed
✅ Ready-to-Cut Design — Pre-formatted, tested layouts — import and cut immediately, no cleanup or adjustments required
✅ Recommended Gauge — Designed & proven on 10, 12 & 14 gauge steel — durable, low-profile builds with reliable strength
✅ Software Compatibility — Optimized for Vectric Aspire, Autodesk Fusion 360, EnRoute, SheetCAM, LightBurn, and most other CNC/plasma/laser programs
✅ Instant Digital Download — Access all files immediately after purchase — start fabricating the same day

Usage & License
✅ You’re welcome to use these files to create and sell your own finished physical products (mounting plates, custom storage solutions, etc.)
✅ Please do not resell, share, distribute, or modify and redistribute the DXF files themselves in any way — this protects the original design

Important Digital Product Info
➤ This is a digital download only – no physical item will be shipped
➤ Files delivered via Etsy instant download link (ZIP containing all 5 files in inches & metric)
➤ As a digital product, all sales are final and non-refundable
➤ If you run into any issues (file compatibility, download problems, etc.), message us right away — we’re fabricators too and will help you get cutting
What's Included
➤ 5 high-quality DXF files (one for each system/size variation, inches primary + metric layers)

Download now and build custom, heavy-duty modular storage mounts with pro-level precision. 🛠️

Thanks for supporting a small USA maker!

Raw Steel: Ships as bare metal—affordable, no added finish cost, and quickest to produce/ship. Ideal if you plan to paint it yourself, weld it further, or want a custom look (e.g., intentional patina or rattle-can paint). Note: Mild steel rusts quickly when exposed to moisture/humidity—store indoors and apply protection soon if used outdoors or in damp garages. Great for budget builds or immediate DIY finishing.

Powder Coat: A baked-on, professional-grade finish (textured black standard). Much tougher than regular paint—resists chips, scratches, fading, and rust far better. Provides excellent protection for job-site, vehicle, or outdoor use (like tool mounts in vans or garages). Adds a small upcharge but delivers a premium, long-lasting look with minimal maintenance. Powder coat also helps hardware stay functional longer by reducing wear.

How do I choose the right gauge for my project?

• Choose thicker gauges (10 or 11) for heavy-duty strength, structural parts, or high-load applications. Example: Using the plate on a horizontal application such floor or dolly.
• Choose thinner gauges (14) for lighter-weight parts, panels, or where cost matters more. Ideal for vertical applications suck as wall or bedside mount.

Why does gauge go backward (lower number = thicker)?
The gauge system originated from the number of draws needed to produce wire/sheet of that thickness. Fewer draws = thicker material = lower gauge number.
