Precision-Engineered Cut Files for High-Quality Fabrication
Grab this precision DXF file and start cutting your custom Milwaukee Packout half-width mounting plate right away on your Plasma, Laser, or Waterjet CNC machine. Designed and carefully verified right here in Southern California, USA by BOCO Custom, this file delivers an exact fit and clean cuts with no wasted material or alignment issues. Replicating the secure locking footprint of half-width Packout accessories, it's the perfect solution for fabricating durable steel mounting bases for garage walls, truck beds, or service van organization.
WHY YOU'LL LOVE IT
-
Dual File Variations: Includes two versions—one with side bends for added rigidity and a flat version for simpler cuts.
-
Inches & Metric Formats: All files are provided in both imperial and metric units for universal compatibility and easy scaling.
-
Tested & Verified: Cut and checked on our own ShopSabre Plasma Table, Xtool P2 Laser, and Gweike M3 Ultra Laser to eliminate errors.
-
Instant Access: Get your digital files immediately after purchase so you can start fabricating today.
| FEATURES & SPECIFICATIONS |
| File Format |
High-Quality DXF (Clean, closed vectors) |
| Units/Scale |
Inches & Metric variations included |
| CNC Compatibility |
Plasma, Laser, Waterjet, Router |
| Commercial License |
Permitted for selling physical cut items (No digital file resale) |
| Origin |
Designed & Made in USA — BOCO Custom |
USAGE NOTES
- Download the file and open it in your preferred CAM/CNC program.
- Select either the flat cut file or the side-bend file depending on your tooling setups.
- Set your kerf/cut width offsets based on your machine's setup and start cutting!
Perfect for: Custom tool walls, service truck beds, enclosed trailers, work benches, and modular garage storage.
FREQUENTLY ASKED QUESTIONS
Is this a physical product?
No. This listing is for an instant digital download of a DXF file only. No physical mounting plates or hardware will be shipped.
Can I sell the plates I cut with this file?
Yes! You are completely free to use this file to fabricate and sell finished, physical products. However, you may not resell, redistribute, or share the digital DXF file itself.
What steel thickness should I use?
We have successfully tested and fabricated these mounting plates using both heavy-duty 10-gauge and lighter 14-gauge steel, depending on the weight load required for your workspace setup.
Rugged Steel Support for Half-Width Modular Tool Boxes
This Packout half width DXF file is designed for tradespeople and DIYers who need a reliable, heavy-duty mounting alternative to standard plastic options. Replicating the modular footprint of half-width systems, this file allows you to cut precision steel bases that secure compact tool boxes, organizers, and bins tightly in place. Built to handle rough treatment, high-vibration vehicle movement, and heavy shop usage, it's a smart addition to any custom organization build.
Flawless Fit with Dual Design Options Included
The digital download includes multiple file formats to match your specific workshop machinery. Choose between a streamlined flat-cut plate or an upgraded design featuring side-bend flanges that offer enhanced stiffness and a clean, flush mounting look. Both paths feature pre-tested, clean geometries to ensure your laser or plasma torch moves smoothly without awkward pausing or edge scarring, leading to a professional-grade finished plate every time.
Optimize Your Vehicle, Garage, or Shop Workspace
A well-organized workspace saves valuable time and keeps your modular tool collection safely stored while traveling. This file provides the foundation to build secure custom mounts for side walls, vehicle floors, slide-out trays, or trailer panels. For small business fabricators or custom builders, this ready-to-cut file provides an easy, highly repeatable way to craft quality storage accessories that expand your project offerings and meet high workplace demands.
10-Gauge Steel (0.1345" | Thickness of Two Stacked Dimes)
- Best For: Heavy-duty commercial wall mounts, shop workbenches, and massive modular tool stacks.
- The Advantage: Extreme structural stiffness. This ultra-thick steel completely eliminates flexing, twisting, and tool rattling, making it the definitive choice for demanding daily job-site use.
12-Gauge Steel (0.1046" | Thickness of a Standard House Key)
- Best For: Mobile service vans, enclosed trailers, and standard shop organization layouts.
- The Advantage: The ultimate sweet spot between bulletproof strength and smart weight distribution. It handles constant over-the-road vibrations flawlessly without adding unnecessary bulk to your mobile rig.
14-Gauge Steel (0.0747" | Thickness of a Nickel)
- Best For: Handheld battery organizers, small tool holsters, and lightweight shelf accessories.
- The Advantage: High-tensile rigidity in a streamlined profile. It provides a rock-solid, permanent mount for smaller gear while keeping your workspace layout clean and low-profile.
8-Gauge Aluminum (0.1285" | Heavy-Duty Marine Grade)
- Best For: Open truck beds, roof racks, exterior trailer sides, and high-moisture environments.
- The Advantage: Maximum corrosion resistance with severe weight savings. Shaved pounds keep your mobile fuel efficiency optimized while remaining completely immune to rain, snow, and road salt oxidation.
10-Gauge Stainless Steel (0.1345" | Thickness of Two Stacked Dimes)
- Best For: Premium exposed truck bed brackets, marine applications, high-end shop builds, and ultimate weather protection.
- The Advantage: Combines the absolute, unyielding structural rigidity of our thickest 10-gauge plate with total lifetime corrosion resistance. It requires no paint or powder coat to stay 100% immune to rust, road salt, and harsh outdoor elements.
Note: Sheet metal gauge numbers run inversely—the lower the gauge number, the thicker and more rigid the actual metal substrate is.
